Ascentta, Inc.

Part Number Index

Ordering Information for Single Mode and Multimode Jumper

JP

Fiber

Connector-1

Connector-2

Cable Type

Fiber Length

JP

S=SMF-28
M5=50/125 Multimode
M6=62.5/125 Multimode

XX=Others

FC=FC/PC
SC=SC/PC
SU=SC/UPC
FA=FC/APC
SA=SC/APC
ST=ST/PC
LC=LC/PC
MC=MU/PC
MA=MU/APC
MTRJ=MTRJ
D4=D4
XX=Others

FC=FC/PC
SC=SC/PC
SU=SC/UPC
FA=FC/APC
SA=SC/APC
ST=ST/PC
LC=LC/PC
MC=MU/PC
MA=MU/APC
MTRJ=MTRJ
D4=D4
XX=Others

B=250um
L=900um
W=2mm
H=3mm

X=Others

10=1.0m
20=2.0m
30=3.0m
35=3.5m

XX=Others

Ordering Information for PM jumper

PMJP

Fiber

Connector-1

Connector-2

Connector Key Alignment

Cable Type

Fiber Length

PMJP

15= Panda PM 1550nm
13= Panda PM 1310nm
10= Panda PM 1060nm
98= Panda PM 980nm

XX=Others

FC=FC/PC
SC=SC/PC
FU=FC/UPC
SU=SC/UPC
FA=FC/APC
SA=SC/APC
ST=ST/PC
LC=LC/PC
MC=MU/PC
MA=MU/APC
MTRJ=MTRJ
D4=D4
XX=Others

FC=FC/PC
SC=SC/PC
FU=FC/UPC
SU=SC/UPC
FA=FC/APC
SA=SC/APC
ST=ST/PC
LC=LC/PC
MC=MU/PC
MA=MU/APC
MTRJ=MTRJ
D4=D4
XX=Others

SX=On Slow Axis
FX=On Fast Axis

B=250um
O=400um
L=900um
W=2mm
H=3mm

X=Others

10=1.0m
20=2.0m
30=3.0m
40=4.0m

XX=Others

Ordering Information for Pigtail

FP

Type

Wavelength

External Diameter

Angle Polish

Fiber Type

Fiber Length

FP

S=Single Fiber

DT=Dual Fiber T Type

DH=Dual Fiber H Type

00=No AR Coating
98=980nm
10=1060n
13=1310nm
14=1480nm
15=1550nm
35=1310/1550nm
95=980/1550nm
XX=Others

18=1.8mm
10=1.0mm

XX=Others

0=0degree
4=4degree
6=6degree
8=8degree
X=Others

B=SMF-28, 250um
L= SMF-28, 900um
PMB=PM Panda, 250um
PML=PM Panda, 900um

X=Others

10=1.0m
15=1.5m
18=1.8m
20=2.0m
28=2.8m
30=3.0m
XX=Others

Ordering Information for Single Mode Collimator

CL

Type

Wavelength

External Dimensions

Package Type

Working Distance

Fiber Type

Fiber Length

Lens

Connector

CL

S=Single Fiber
DT=Dual Fiber T Type
DH=Dual Fiber H Type

00=No AR Coating
98=980nm
10=1060n
13=1310nm
14=1480nm
15=1550nm
35=1310/1550nm
95=980/1550nm
XX=Others

A=3.20*9.5mm
B=2.78*9.0mm
C=2.40*9.0mm
D=1.40*6.5mm
E=1.27* 6.5mm
X=Others

M=Metal Holder
G=Glass Tube

05=5mm
10=10mm
20=20mm
...
70=70mm
XX=Others

B=SMF-28, 250um
L= SMF-28, 900um

X=Others

10=1.0m
15=1.5m
18=1.8m
20=2.0m
28=2.8m
30=3.0m

XX=Others

G=G Lens
C=C Lens

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC
ST=ST/PC
LA=LC/APC
LC=LC/PC
XX=Others

Ordering Information for PM Collimator

PMCL

Type

Wavelength

External Dimensions

Package Type

Working Distance

Fiber Type

Fiber Length

Lens

Connector

PMCL

S=single fiber
D=dual fiber (for 1.8mm only)

00=No AR Coating
13=1310nm
15=1550nm
XX=others

A=3.20*9.5mm
B=2.78*9.0mm
C=2.40*9.0mm
D=1.40*6.5mm
E=1.27* 6.5mm
X=Others

M=Metal Holder
G=Glass Tube

05=5mm
10=10mm
20=20mm
....
X= Others

PMB=250um panda fiber
PMO=400um panda fiber
PML=900um panda fiber
X - Others

10=1.0m
15=1.5m
18=1.8m
20=2.0m
28=2.8m
30=3.0m

G=G Lens
C=C Lens

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC

Ordering Information for Single Mode Isolator

IS

Type

Wavelength

Fiber Type

Fiber Length

Connector

IS

S=single stage
D=dual stage

10=1064nm
13=1310nm
14=1480nm
15=1550nm
18=1585nm

XX=Others

B=SMF-28 250um
L=SMF-28 900um

X=Others

10=1.0m
20=2.0m
XX=Others

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC
ST=ST/PC
LA=LC/APC
LC=LC/PC
XX=Others

Ordering Information for PM Isolator

PMIS

Type

Wavelength

Fiber Type

Fiber Length

Connector

PMIS

S=single stage
D=dual stage

10=1064nm
13=1310nm
14=1480nm
15=1550nm
CL=C+L band
18=1585nm

XX=Others

PMB=250um Panda fiber
PMO=400um Panda PM fiber
PML=Panda PM fiber with 900um loose tube
XXX=Others

10=1.0m
15=1.5m
20=2.0m

30=3.0m

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC
ST=ST/PC
LA=LC/APC
LC=LC/PC
XX=others

Ordering Information for High Power Isolator

HIS

Type

Wavelength

Fiber Type

Fiber Length

Connector

Max. Power Handling

HIS

S=Single Stage
D=Dual Stage

10=1064nm
13=1310nm
14=1480nm
15=1550nm
18=1585nm
XX=Others

B=SMF-28, 250um
L=SMF-28, 900um

X=Others

10=1.0m
15=1.5m
20=2.0m

30=3.0m

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC
ST=ST/PC
LA=LC/APC
LC=LC/PC
XX=Others

valign="top">

2W=2000mW
5W=5000mW

Ordering Information for Multimode Isolator

MMIS

Type

Wavelength

Fiber

Cable Type

Fiber Length

Connector

MMIS

S=Single Stage
D=Dual Stage

10=1064nm
13=1310nm
15=1550nm

M6=62.5um
M5=50um

B=250um
L=900um
H=3mm

10=1.0m
15=1.5m
20=2.0m
30=3.0m
XX=Others

NE=None
FC=FC/PC
SC=SC/PC
ST=ST/PC
LC=LC/PC
XX=Others


Ordering Information for Free Space Isolator

FSI

Type

Stage

Latching Type

Wavelength

Clear Apture

Package Dimension

FSI

PD=Polarization Dependent

PI=Polarization Independent

S=Single Stage
D=Dual Stage

L=Latching Type Garnet (Without Magnet Ring)

N=Non-latched type Garnet (with Magnet Ring)

10=1064nm
13=1310nm
15=1550nm
51=1510nm
59=1590nm
XX=Others

05=0.5mm
09=0.9mm
12=1.2mm

XX=Others

01=2.5*2.15*1.8mm 02=2.5*2.15*2.0mm 03=2.5*2.15*2.6mm
04=2.5*2.15*3.0mm
05=Φ 2.5*2.1mm 06=Φ2.99*3.0mm
07=Φ 2.5*2.0mm
08=Φ2.5x1.8mm 09=Φ2.5*2.6mm 10=Φ2.5*3.0mm
11=Φ 2.5*1.4mm
12=Φ2.99*1.4mm
XX=Others

Ordering Information for Pigtailed Isolator

PFSI

Latching Type

Wavelength

Clear Apture

Housing Length

Fiber Length

Connector

PFSI

L=Latching Type Garnet (Without Magnet Ring)

N=Non-latched type Garnet (with Magnet Ring)

13=1310nm
15=1550nm
51=1510nm
59=1590nm
XX=Others

05=0.5mm
09=0.9mm
12=1.2mm

XX=Others

10=10mm
14=14.4mm

10=1.0m
15=1.5m
20=2.0m
30=3.0m
XX=Others

NE=None
FC=FC/PC
SC=SC/PC
ST=ST/PC
LC=LC/PC
XX=Others

Ordering Information for Receptacle Isolator

RFSI

Latching Type

Wavelength

Clear Apture

Connector

RFSI

L=Latching Type Garnet (Without Magnet Ring)

N=Non-latched type Garnet (with Magnet Ring)

13=1310nm
15=1550nm
51=1510nm
59=1590nm
XX=Others

05=0.5mm
09=0.9mm
12=1.2mm

XX=Others

SC=SC/PC
LC=LC/PC

XX=Others

Ordering Information for CWDM Filter

CWDMF

Wavelength

Fiber Type

Fiber Length

Connector

CWDMF

47=1470nm
49=1490nm
51=1510nm
53=1530nm
55=1550nm
57=1570nm
59=1590nm
61=1610nm
XX=Others

B=SMF-28, 250um
L=SMF-28, 900um

X=Others

10=1.0m
25=2.5m
XX=Others

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC
ST=ST/PC
LA=LC/APC
LC=LC/PC
XX=Others

Ordering Information for CWDM Module

CWDM

Channels

Start Channel

Fiber Type

Fiber Length

Connector

CWDM

4=4 Ch
8=8 Ch

47=1470nm
49=1490nm
51=1510nm
53=1530nm
55=1550nm
57=1570nm
59=1590nm
61=1610nm
XX=Others

B=SMF-28, 250um
L=SMF-28, 900um
H=SMF-28, 3mm

X=Others

10=1.0m
25=2.5m
XX=Others

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC
ST=ST/PC
LA=LC/APC
LC=LC/PC
XX=Others

Ordering Information for DWDM Filter

DWDMF

Wavelength (ITU)

Fiber Type

Fiber Length

Connector

DWDMF

21=ITU 21
22=ITU 22
23=ITU 23
XX=Others

B=SMF-28, 250um
L=SMF-28, 900um

X=Others

10=1.0m
25=2.5m
XX=Others

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC
LC=LC/PC
XX=Others

Ordering Information for DWDM Module

DWDM

Channel Spacing

Channels

Configuration

Start ITU Channel

Fiber Type

Fiber Length

Connector

DWDM

1=100GHz 2=200GHz

02=2 Ch
04=4 Ch
16=16 Ch

XX=Others

M=Mux
D=DeMux

21=ITU 21
22=ITU 22
23=ITU 23
XX=Others

B=SMF-28, 250um
L=SMF-28, 900um
H=SMF-28, 3mm

X=Others

10=1.0m
25=2.5m
XX=Others

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC
ST=ST/PC
LA=LC/APC
LC=LC/PC
XX=Others

Ordering Information for Single Mode Circulator

CIR

Port

Wavelength

Fiber Type

Fiber Length

Connector

CIR

3=3 Port
4=4 Port


13=1310nm
15=1550nm
L=1565~1625nm
CL=1520~1625nm

B= SMF-28, 250um
L= SMF-28, 900um

X=Others

10=1.0m
15=1.5m
20=2.0m

XX=Others

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC
ST=ST/PC
LA=LC/APC
LC=LC/PC
XX=Others

Ordering Information for PM Circulator

PMCIR

Port

Wavelength

Fiber Type

Fiber Length

Connector

PMCIR

3=3-port
4=4-port

13=1310nm
15=1550nm
L=1565~1625nm
CL=1520~1625nm

PMB=PM PANDA 250um
PML= PM PANDA 900um

PMX=Others

10=1.0m
15=1.5m
20=2.0m

XX=Others

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC
ST=ST/PC
LA=LC/APC
LC=LC/PC
XX=Others

Ordering Information for WDM

FWDM

Wavelength

Fiber Type

Fiber Length

Connector

FWDM

35=1310pass/1550 reflect
53=1550pass/ 1310 reflect
45=1480pass/1550 reflect
54=1550pass/ 1480 reflect
95=980pass/1550 reflect
59=1550pass/980 reflect
15=1510pass/1550 reflect
51=1550pass/1510 reflect
49=1480pass/1590 reflect
94=1590pass/1480 reflect

XX=Others

B= SMF-28, 250um
L= SMF-28, 900um

X=Others

10=1.0m
15=1.5m
20=2.0m

XX=Others

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC
ST=ST/PC
LA=LC/APC
LC=LC/PC
XX=Others

Ordering Information for Manual Variable Optical Attenuator

MVOA

Wavelength

Fiber Type

Fiber Length

Connector

MVOA

13=1310nm
15=1550nm
35=1310/1550nm

XX=Others

B=SMF-28, 250um
L= SMF-28, 900um
W= SMF-28, 2mm
H= SMF-28, 3mm

X=Others

10=1.0m
25=2.5m
30=3.0m
40=4.0m

XX=Others

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC
ST=ST/PC
LA=LC/APC
LC=LC/PC
XX=Others

Ordering Information for Polarizer

PLZ

Type

Wavelength

Fiber-In

Fiber-Out

Fiber Length

Connector

PLZ

IL=In Line
FS=Free -Space

10=1064nm
13=1310nm
14=1480nm
15=1550nm
19=1590nm
98=980nm
XX=Others

NF=No Fiber
B=SMF-28, 250um
L=SMF-28, 900um
PMB=PM panda, 250um
PMO=PM panda, 400um
PML=PM panda, 900um

NF=No Fiber
PMB=PM panda, 250um
PMO=PM panda, 400um
PML=PM panda, 900um

10=1.0m
15=1.5m
20=2.0m
30=3.0m
XX=Others

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC
ST=ST/PC
LA=LC/APC
LC=LC/PC
XX=Others

Ordering Information PM Tap Coupler

PMTC

Wavelength

Coupling Ratio

Fiber Type at Output and Input Port

Fiber Type at Tap Port

Fiber Length

Connector

PMTC

10=1064nm
13=1310nm
14=1480nm
15=1550nm

50=50/50
30=30/70
20=20/80
05=5/95
01=1/99

PMB=PM Panda, 250um
PMO=PM Panda, 400um
PML=PM Panda, 900um

B=SMF-28, 250um
PMB=PM Panda, 250um

10=1.0m
15=1.5m
20=2.0m
...
30=3.0m

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC

Center Wavelength

nm

1310, 1480 or 1550

980

Ordering Information for Polarization Beam Splitter / Combiner

PBC

Wavelength

Fiber Type at Dual-Fiber End

Fiber Type at Single-Fiber End

Fiber Length

Connector

PBC

13=1310nm
14=1480nm
15=1550nm
98=980nm

PMB=PM Panda, 250um
PMO=PM Panda, 400um
PML=PM Panda, 900um

SB=SMF-28, 250um
(HI1060 for 980 PBC/PBS)
PMB=PM Panda, 250um
PMO=PM Panda, 400um
PML=PM Panda, 900um

X=Others

10=1.0m
20=2.0m
XX=Others

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC
ST=ST/PC
LA=LC/APC
LC=LC/PC
XX=Others

Ordering Information for Short Wavelength Isolator

VIC

Type

Wavelength

Clear Aperture

Max. Power

VIC

S=Single Stage
D=Dual Stage

980=980nm
1025=1025nm
1047=1047nm
1053=1053nm
1064=1064nm
1080=1080nm
XXX=Others

09=0.9mm
15=1.5mm
20=2.0mm

XX=Others

03=0.3W
10=1.0W
50=5.0W

XX=Others

Ordering Information

VIS

Type

Wavelength

Fiber Type

Cable Type

Fiber Length

Connector

Max. Power

VIS

S=Single Stage
D=Dual Stage

980=980nm
1025=1025nm
1047=1047nm
1053=1053nm
1064=1064nm
1080=1080nm
XXX=Others

H1=HI-1060
PM9=PM980

XX=Others

B=250um
L=900um
H=3mm

10=1.0m
15=1.5m
20=2.0m
30=3.0m

XX=Others

NE=None
FC=FC/PC
SC=SC/PC
ST=ST/PC
LC=LC/PC
XX=Others

03=0.3W
10=1.0W
50=5.0W

XX=Others

Ordering Information for Coupler


CP

Type

Wavelength

Coupler Ratio

Port

Pack-
age

Fiber Type

Cable Type

Fiber Length

Connector

CP

S=Standard
W=Wide- Band
D=Dual-
Window
T=Tri- Window
SC=Mode Scrambler

85=850
98=980
10=1060
13=1310
15=1550
35=1310/1550
CL=C+L

XX: Others

50=50/50
01=01/99

XX=others

12=1x2
22=2x2
13=1x3
14=1x4

XX= Others

M
N
A
B
C
E
F
G
H
J
K
L

S=SMF-28
fiber
M5=50u MM fiber
M6=62.5u MM fiber
H1=1060
Flexcore
PM=PM Panda fiber

X= Other

B=250um

L=900um

H=3mm

10=1.0m
15=1.5m
20=2.0m

XX=Others

NE=None
FA=FC/APC
FC=FC/PC
SA=SC/APC
SC=SC/PC
LC=LC/PC
XX=Others

Package Dimensions:
M: 3mm x 40mm stainless steel tube
N: 3mm x 48mm stainless steel tube
A: 3mm x 54mm stainless steel tube
B: 3mm x 60mm stainless steel tube
C: 8.5mm x 14mm x 98mm case
E: 3mm x 35mm stainless steel tube
F: 3mm x 35mm stainless steel tube
G: 2.4mm x 30mm stainless steel tube
H: 2.4mm x 25mm stainless steel tube
J: 2.4mm x 18mm stainless steel tube
K: 4mm x 45mm stainless steel tube
L: 4mm x 56mm stainless steel tube

© 2016 Ascentta, Inc.

370 Campus Dr. Suite 105, Somerset, NJ 08873

Phone:732-868-1766

Email: sales@ascentta.com

Terms of Use
